TUBULAR

T60 PMMA


T60 PMMA is good for anti UV & Ammonia, high protection IP69K & IK09 is suitable for multiple industrial and Agricultural applications. DLG certified product which is allowed for professional farm applications for NH3 proof.




SizeWattageLumenEfficiencyCRICCTSDCMWaterproofIK Rate
600mm20W3200LM160lm/w804000K3IP69KIK09
1200mm36W5760LM160lm/w804000K3IP69KIK09
1500mm48W7680LM160lm/w804000K3IP69KIK09


Name

Description

Surface mounting Bracket

Surface mounting Bracket

Stainless steel 316 material; Used of Suspending and ceiling mounted; 2pcs/set

Anti-thief bracket

Anti-thief bracket

Stainless steel 316 material; Used of Suspending and ceiling mounted; 2pcs/set

Anti-vibration bracket

Anti-vibration bracket

Stainless steel 316 material; Used of Suspending and ceiling mounted; 2pcs/set

Suspending Cable

Suspending Cable

Stainless steel material; Used of suspending; 2pcs/set

Structure Data

Input: AC220~240V 50/60Hz
Wiring: 3 wires through optional
Operation Temp: -20~40°C
Function: 1~10V DIM | Dimmable | Motion Sensor | Emergency
Flicker: Flicker free
Material: PMMA+Stainless Steel 316
Installation: Ceiling mounted | Suspension | Wall Mounted
Protection: IP69K | IK09 | IK06
Terminal: 3x1.5mm² | M20 Connector



Download
Manual

Manual-Tri-proof-light-T60 PMMA V2.pdf

Download
IES Files

T60 IES.zip

Download
Integrating Sphere

T60.zip

Download
Specification

SPEC-T60 V3.pdf

Download
